Description
Draughtsman Mechanical Second Year MCQ is a simple e-Book for ITI Engineering Course Revised NSQF Syllabus, Draughtsman Mechanical Second Year. It contains objective questions with underlined & bold correct answers MCQ covering all topics including all about the latest & Important about skill in CAD application practical assignments are given by using commands in various methods. Detail and assembly drawing of machine parts viz., Pulleys, Pipe fittings, Gears and Cams applying range of cognitive and practical skills. Construct production drawing applying quality concept in CAD. Creation of objects in 3D Modeling Space and generate views, print preview to plot in .dwgand .pdf format. Individual skill is developed by preparing production drawing of machine parts applying conventional sign and symbol by taking measurement. Impart knowledge to draw workshop layout of a production industry considering process path and human ergonomics. In SolidWorks/AutoCAD Inventor/ 3D modeling environment the assignment is to create and plot assembly and detailed views of machine parts with dimensions, annotations, title block and bill of materials. and lots more.
Author: Manoj Dole
Publisher: Notion Press
Published: 09/06/2022
Pages: 96
Binding Type: Paperback
Weight: 0.31lbs
Size: 9.00h x 6.00w x 0.20d
ISBN13: 9798888057865
ISBN10: 8888057862
BISAC Categories:
- Study Aids | Vocational
