Description
Design in SketchUp
Document in LayOut
Learn how to use SketchUp and LayOut to design and document any architectural project from concept to completion.
This step-by-step workflow shows you how to create a 3D terrain model of your existing site, then walks you through modeling the building and producing documents throughout each design phase.
- Use the Sandbox tools to create and modify 3D terrain to build an existing site model and a proposed site model.
- Organize your model into multiple files to increase speed, performance, and enable better scene & section plane management.
- Learn how to use multiple viewports in LayOut to illustrate your section cuts clearly, while taking advantage of colorful textures applied to the model.
- Define the level of detail required in your model to enable you to make fast changes throughout each phase of design.
- Learn how to use SketchUp and LayOut templates to improve your workflow.
A complete sample project is included with this book to help you explore a real project and see how it is organized. In addition, an entire set of template files are included for you to customize for your own use.
Author: Matt Donley, Nick Sonder
Publisher: Bizfound, LLC
Published: 06/06/2016
Pages: 340
Binding Type: Paperback
Weight: 1.49lbs
Size: 10.00h x 8.00w x 0.71d
ISBN13: 9780996539326
ISBN10: 0996539328
BISAC Categories:
- Architecture | Design, Drafting, Drawing & Presentation
- Computers | Design, Graphics & Media | CAD-CAM
- House & Home | Design & Construction
