The Yamaha XS650 Engine: Including the Electrical System

This book provides a very detailed description of the function of the Yamaha XS 650 engine, which is based on more than 400 color photos. With the help of this book anyone who has the necessary equipment and basic knowledge should be able to perform maintenance and repair-work. Problems in the electrical system are actually easy to fix. If you don't want to do it by trial and error, this book helps you to understand the electric system of the XS 650. On 35 pages with 38 color photos and graphics you will find an extensive description of the function and how to test all components of the power supply. In addition, a highly simplified wiring harness, which contains all the necessary functions, is described. New spare parts are rarely available. So a whole chapter with 34 color photos is dedicated to the description of typical damages. It will help you to recognize the beginning of wear and to decide wether a part should be replaced or not.

Author: Hans Joachim Pahl
Publisher: Createspace Independent Publishing Platform
Published: 04/16/2017
Pages: 168
Binding Type: Paperback
Weight: 0.70lbs
Size: 9.02h x 5.98w x 0.44d
ISBN13: 9781544270630
ISBN10: 1544270631
BISAC Categories:
- Technology & Engineering | Automotive

About the Author
Hans J. Pahl is a German automotive engineer, who worked a couple of years as a design engineer with a medium sized company, which specialized in special purpose vehicles - mainly heavy duty trucks for oil fields and airfield fire engins. He worked 15 years in the R&D department and as a product developer with an international company in the automotive supply industry. Since 2002 he works as traffic accident investigator and as an expert for vehicle technology. Hans J. Pahl has been riding motorcycles for 45 years now and since more than 20 years he owns a Yamaha XS 650 with a mileage of about 200.000 miles now.

This title is not returnable
